HOWO Concrete Howo mixer truck is optimization of body structure, special mold production, beautiful appearance, concrete mixing, discharge uniformity, low rate of residual. Cost-effective concrete mixer truck with competitive price is your best choice.
1.Product Introduction
SINOTRUK HOWO 6×4 Concrete mixer truck suitable for agitating and transiting concrete, for construction site, road repairing and some other infrastructure construction business. Concrete Howo mixer truck is optimization of body structure, special mold production, beautiful appearance, concrete mixing, discharge uniformity, low rate of residual. Cost-effective concrete mixer truck with competitive price is your best choice.
2.Product Details
3.Product Parameter (Specification)
| Model | Chassis model: ZZ1257N3847D1 | |
| Engine | D10.38-40(380Hp at 2000r/min, Euro IV)1560Nm at 1200-1500r/min, With PTO | |
| Clutch | Single-plate dry diaphragm spring clutch, diameter 430 mm, hydraulically operating with air assistance | |
| Transmission | HW19710, 10 forward and 2 reverse, manual | |
| Propeller Shaft | Double universal joint propeller shaft with gear-shaped coupling flange | |
| Front Axle | HF9 (9000Kg) | |
| Rear Axles | HC16 (2x16000Kg) Ratio: 5.73 | |
| Chassis | Enhanced version of multiple-leaf spring (Front 9 pieces, Rear 12 pieces) | |
| Fuel tank | With one 400 L fuel tank with locking fuel cap | |
| Steering | ZF power steering, model ZF8118, hydraulic steering with power assistance
Ratio: 22.2-26.2 |
|
| Brakes | Service brake: dual circuit compressed air brake
Parking Brake (emergency brake): spring energy, compressed air operating on rear wheels Auxiliary brake: engine exhaust brake |
|
| Wheel & Tires | Rims width: 8.5
Tires: 12.00R20 |
|
| Cab | HW76 cab, one sleeper, all steel forward control, 55°hydraulically tiltable to the front, 2-arm windscreen wiper system with 3 speeds, laminate windscreen, with casted-in radio aerial, hydraulically damped adjustable driver’s seat and rigid adjustable co-driver’s seat, heating & ventilation system, exterior sun visor, stereo radio, safety belts, air horn, air conditioner, and single berths with 4-point support fully floating suspension and shock absorber with transverse stabilizer, safety belt, adjustable roof flap. | |
| Electrics | Operating voltage:24V, negative grounded; Starter: 24V, 5.4KW
Alternator: 3-phrase, 28V, 2240W; Batteries: 2×12, 165Ah Cigar-lighter, horn, headlamp, fog light, brake lights, indicators and reverse lamp |
|
| Cargo Body | 10m³, American Eaton brand pump, American Eaton brand motor, Italy Bonfiglioli speed reducer
Tank head 6 mm, body 5 mm |
|
| Dimensions in mm | Wheel base
Front wheel track Rear wheel track Front overhang Rear overhang Approach angle(o) Departure angle(o) Overall Dimension |
3800+1400
2022 1830 1500 1860 16 24 9220x2500x3930 (mm) |
| Weight in kg | Net weight
Gross Vehicle Weight Front axle loading capacity Rear axle loading capacity |
14500
41000 9000 16000×2 |
| Performance | Maximum driving speed(km/h)
Maximum grade ablility (%) Minimum ground clearance(mm) Minimum turning circle(m) |
85
35 290 15 |
| Optional | ABS
Air conditioner Tires Bumper Truck color Intercooler Protector Fire Extinguisher |
|
5.Special service team with technial engineers is ready if any quality complains, will respond in 48 hours with feedback and solution.
1.Competitive Factory Price and Excellent Quality
2.More than 20 years’ experience as a manufacturer
3.Products Quality Certification SGS CCC ISO
4.Perfect after-sale service
5.Customized products available with us
6.Export to more than 50 countries and regions
7.Oversea wareshouse with more than 100000 US dollors spare parts in stock
8.Oversea office with more than 15 professional engineers to help local customers
LUCKIN VEHICLE promises that “Good is not enough when better is available.”We sincerely look forward to your visiting and calling.
