4 Axles U Box 100T Rear Tipper Semi Trailer

Products

4 Axles U Box 100T Rear Tipper Semi Trailer

share to:

LUCKIN VEHICLE supply 4 Axles U Shape Rear Dump Semi Trailer for Negria, also known as dump semi-trailer, which is normally used to transport unpacked and bulk goods, such as coal, ore, sand and construction materials and etc. We support designing and production according to customers’ different needs, such as sizes, axles, suspensions, box types and capacity.



Lead Time:20 days

Shipping Port:Any Port Of China

Payment:T/T;L/C

4 Axles U Box 100T Rear Tipper Semi Trailer

4 Axles U Box 100T Rear Tipper Semi Trailer插图

Product Parameter (Specification)

Dimension(L*W*H): 11500*2650*3800 (mm) (Customized Sizes or Designed according to customers’ needs)

Thickness: Side wall:8 mm; bottom floor:8 mm

Payload (Kg): 100000

Volume (CBM): 50 CBM

Hydraulic system: HYVA Brand

Kingpin: JOST 3.5”/2.5” bolt-in type

Landing gear: JOST 19”

Tires: 315/80R22.5

Axle: FUWA/BPW or other Brands

Suspension: Heavy duty mechanical suspension with springs/Air suspension/Bogie suspension

Brake system: Dual line with WABCO brand Re-6 emergency relay valve, T30/30 air chamber, 45L air tanks

Electric system: One unit of 24V 7-pin ISO standard socket; with brake light, turn light, reverse light, side light, reflector, fog light; one set of 6-pin standard cable

Product Introduction

4 Axles U Shape Rear Dump Semi Trailer is more and more popular to transport coal, ore, building materials and other bulk and unpacked goods.

Bottom and top plate of the dumper trailer would be designed according to international transport standards and different country needs. Normally we would use 8mm and 6mm thickness plat steel to match the heavy loads’ usage, with high resistance, enabling maximum efficiency in any road and weather conditions. The bucket body is made of durable steel, which can withstand the wear and impact of 450HB. The end cover is connected with an adjustable spring that can be opened and closed from the bottom.

4/5 axles Heavy duty tipper dump trailers are playing more and more roles in west Africa countries, such like Cote d ‘Ivoire, Guinea, Ghana and ect.
