LUCKIN tanker trailer fuel tanker trailer, adopt advanced design concept. Our fuel tanker trailer choose Q345B carbon high-tensile steel material, welded by automatic Submerged-Arc processes. We adopt world famous brand of parts, like JOST, WABCO braking valve etc.
Lead Time：20 days
Shipping Port：Any Port Of China
Payment：T/T;L/C
Product Parameter
Items:Fuel/Oil tank trailer QUEST9402GYYA
Loading Capacity:30-50 cbm
Axle:3 pieces, 13T FUWA/BPW axle
Tyre:12 pieces, 12R22.5
Dimensions(LxWxH):9000 to 13000mm x 3000 x 3700mm
Tare weight:9 tons to 11 tons
Axle spacing:1310mm
Rims:8.5-20, 9.0-20
Suspension System:Leaf spring suspension / air suspension
Brake System:Dual line pneumatic brake system with WABCO emergency relay valve
Main Beam:Height 500mm Q345
Chassis:upper 20mm, lower 20mm. Mid web 12mm
Compartment:Single or 2/4/optional
Fire Extinguisher:2 pieces
Related Valves:One whole set of valves
Kingpin:2′ or 3.5′ interchangeable
Landing Gear:28 Tons , Two speed manual operation
Electrical System:1.Voltage: 24v 2. Receptacle: 7 ways (7 wire harness) German standard
Lights and Reflectors:Rear light, rear reflector, turn indicative light, side reflector, fog lamp, number plate light
Painting:Shot blast to SA 2.5 Standard prior to application of primer, polyurethane top coat. Total DFT not less than 100μm;Any color will be available
Tool Box:One tool box with a set of standard trailer tools
Spare Tyre Carrier:One piece or two pieces
Product Introduction
Luckin 3 Axles Aluminum Alloy Oil Tanker Semi Trailers adopt advanced design concept and production Process to fabric the most durable tank trailers especially for African Market considering the road condition and customer’s special requirements. And its distortion resistance, earthquake resistance and bump are very helpful for your transport safety.
LUCKIN VEHICLE offers carbon steel, stainless steel or aluminum material 3 Axles Aluminum Oil Tanker Semi Trailer. The volume of the 3 Axle Oil Tanker Trailers can be customized, such as 40,000 liters, 45,000 liters, 54,000 liters, up to 90,000 liters. Also with different compartments, like two, three, four, or more compartments, you can load different liquids as you want separately.
LUCKIN VEHICLE supply 3 Axles Aluminum Alloy Oil Tanker Semi Trailer, which is normally used to transport fuel, gasoline, diesel, crude oil, palm oil, water, liquid chemicals, edible oil, etc. And you can customize fuel tank trailers as you want, such as sizes, shape, materials, axle numbers and so on.
LUCKIN VEHICLE promises that “Good is not enough when better is available.”We sincerely look forward to your visiting and calling.
